| Production Rate |
Max. 5,000 lbs./hr(2,270kg/hr)
Higher rate can be achieved with HITEC's optional unit. |
| Casing Size |
Casing Size Cellulose casing code 13 through 36.
Larger sizes can be applied with HITEC's optional unit. |
| Product Size |
3 pitches (1 1/8
in, 28.4mm) through 32 pitches (12 in, 305mm) or more |
The figures shown above may change depending on the product, plant condition,
local requirements for power and/or other respective matters.
|
| Casing Shirred Length |
Max. 16 1/2 in (419mm)
cellulose casing |
| Pneumatic Requirements |
Pressure: 75psi
(5.3kg/cm2)
Consumption:73 in3 (1,200cm3) per cycle |
| Height |
57 1/2 in (1,460 mm) |
| Width |
25 5/8 in (650 mm) |
| Length |
119 3/4 in (3,040 mm) |
| Weight |
Appro. 330 lbs (150 kg) |
| Power requirements |
Three-phase, 0.75kW
Any special local requirements must be so
advised. |
In addition to M-2, HITEC M-2L (able to combine with COSMO or STANDARD LOOPER) designed for casing shirred length of MAX.
21 1/2 in (546 mm) is recommended.
Specifications and equipment are subject to change without any obligation
on the part of the manufacturer.
|
