| Production Rate |
Artificial Casing：Max. 3,200kg/hr (7,000 lb/hr)
Natural Casing： Max. 800pcs./min |
|
Dependent on casing quality, product size, weight and/or factory conditions.
|
| Product Size |
Artificial Casing：3 pitches (28.6 mm , 1 1/8 in)
through 32 pitches (304.8 mm, 12 in) or more.
Natural Casing：3pitches (28.6 mm , 1 1/8 in )
through 20 pitches (190.5 mm, 7 1/2 in)or more |
| Casing
Size |
Sheep Casing 14mm-25mm
Hog Casing 26mm～36mm
Artificial 13mm ～ 32mm |
| Height |
1,851mm (72 7/8 in) |
| Weidth |
817mm (32 3/16 in) |
| Length |
1,195mm (47 1/16 in) |
| Weight |
Approx 400kg (882 lbs) |
| Power
Requirements |
Three-phase, 6.7kw
Any special local requirements must be so advised. |
| Pneumatic
Requirements |
Pressure 0.5Mpa (75
psi) |
Specifications and equipment are subject to change without any obligation
on the part of the manufacturer.
The above production rate is subject due to the condition such as
production item, factory and other conditions.
|
